TYSUU 4002(202\208) Series Mechanical Seal

Operating Limits

Sealing chamber pressure: ≤0Mpa~1.2Mpa
Seal cavity temperature: - 20~80°C( -30~200°C)
Linear speed: ≤12m/sec
Medium: water, oil and sewage with PH value of 6.5-8
Uses: clean water pumps, sewage pumps, submersible pumps, chemical pumps and other equipment, used to transport oil,Water and weak corrosive solutions.

Double Face Mechanical Seals

●Double Face

●Single Spring

●Unbalanced Seal

●Rubber Bellows

Stationary Ring(Ceramic/SiC/TC)
Rotary Ring(Carbon/SiC)
Secondary Seal(NBRNITON)
Retainer(SUS304/SUS316)
Spring(SUS304/SUS316)
Spring Holder(SUS304/SUS316)

Contact form

ABOUT

Zhejiang Tianying Mechanical Seals Co., Ltd. is TYSUU 4002(202\208) Series Mechanical Seal supplier and manufacturer in China, factory covering an area of ??22,000 square meters and employing 250 people. After nearly 30 years of unremitting efforts and development, 84 series and more than 1000 types of medium mechanical seals have been developed. Wholesale TYSUU 4002(202\208) Series Mechanical Seal supplier direct from our company. OEM/ODM available.

₊
Experience
Employees
_㎡
Plant Area
₊
Model

factory equipment

Our factory has sound facilities and full functions,
which is very suitable for mass production.

Related Products

TYS 1011 Cartridge Mechanical Seal 12mm16mm 22mm for GF CR CRN CRI pump seal

TYS 1006 Mechanical seal John crane type 2100K pump shaft seal

TYS 1008 Pump seal supplier bellow Mechanical Seal MG9 MG912 for water pump

TYS1009、MG1、MG12、MG13 Rubber bellows mechanical seal professional mechanical seal supplier

TYS58U Mechanical seals for IMO water pump

TYS 155 Single spring mechanical seals for water pump seal

TYS 301 John crane mechanical seal for chemical pump

TYS 303C Mechanical Seal Auto Cooling Pump Seal

MODEL	d1	D7	L	L2	L30	D19	D20	D21
TYSUU 4002-12	12	26	38	5	6.5	39.5	M5x3	51
TYSUU 4002-14	14	28	38	5	7.3	39.5	M5x3	51
TYSUU 4002-16	16	28	38	5	7.3	39.5	M5x3	51
TYSUU 4002-18	18	33	40	6	7.8	42	M5x3	62
TYSUU 4002-20	20	35	40	6	7.8	42	M5x3	51
TYSUU 4002-22	22	37	42	6	7.8	42	M5x3	51
TYSUU 4002-25	25	40	48	6	7.8	47	M5x3	56
TYSUU 4002-28	28	43	51	6.0		47	M5x3	56
TYSUU 4002-30	30	45	51	6.0	8.5	53	M5x3	62
TYSUU 4002-35	35	50	51	6.0	8.5	63	M5x3	76
TYSUU 4002-40	40	58	58	8	11	73	M5x4	90
TYSUU 4002-45	45	63	58	8	11	78	M5x6	95
TYSUU 4002-50	50	70	66	8.5	12	83	M5x6	100
TYSUU 4002-55	55	75	70	8.5	12	88	M5x6	105
TYSUU 4002-60	60	80	70	9	12.5	93	M5x6	110
TYSUU 4002-12XJ	12	26	30	5	/	/	/	/
TYSUU 4002-14XJ	14	26	35	5	/	/	/	/
TYSUU 4002-18XJ	18	33	38	6	/	/	/	/
TYSUU 4002-17	17	35	40	6	/	/	/	/
