TYS 1006 Mechanical seal John crane type 2100K pump shaft seal

Operating Limits

Annular Seal Pressure:≤OMpa~1.2Mpa
Annular Seal Temperature: -20~80℃(-30~200℃)
Rotation speed:≤12m/sec
Medium: water, oil and sewage with PH value of 6.5-8
Mainly used in various centrifugal pumps, pipeline pumps, industrial pumps, vortex pumps, etc.

Single end face
Single bullet
Unbalanced seal
Rubber bellows
Any rotation

Static Ring (Silicon Carbide/Tungsten Carbide)
Moving ring (graphite/silicon carbide)
Auxiliary sealing (nitrile rubber/ethylene propylene rubber/fluorine rubber/hydrogenated nitrile)
Transmission sleeve (stainless steel)
Spring (stainless steel)
Spring seat (stainless steel)

Contact form

MODEL	d1	d3	D7	L	L28	L2
TYS1006-12	12	28	26	23	6.5	5.0
TYS1006-14	14	32	28	25	6.5	6.0
TYS1006-16	16	32	27	25	6.5	6.0
TYS1006-18	18	39	33	27	7.5	6.0
TYS1 006-20	20	39	35	29	7.5	6.0
TYS1006-25	25	46	40	31	7.5	6.0
TYS1006-28	28	51	43	34	7.5	6.0
TYS1006-30	30	51	45	34	7.5	6.0
TYS1006-35	35	59	50	36	7.5	6.0
TYS1006-40	40	66	58	39	9	8.0
TYS1006-45	45	72	63	39	9	8.0
TYS1006-50	50	77	70	40	9.5	8.0
TYS1006-55	55	84	75	46	11	8.5
TYS1006-60	60	88	80	49	11	9.0
TYS1006-65	65	97	85	51	11	9.0
TYS1006-70	70	104	92	51	11 .3	9.0
TYS1006-75	75	110	97	51	11 .3	9.0
TYS1006-80	80	116	105	52	12	10
TYS1006-85	85	124	110	55	14	10
TYS1006-90	90	131	115	59	14	10
TYS1006-95	95	136	120	60	14	10
TYS1006-100	100	141	125	61	14	10
TYS1006-110	110	150	140	61	14	10
TYS1006-120	120	160	150	61	14	10
TYS1006-12d	12	28	23	21	6.5	5.5
TYS1006-14d	14	32	25	23	6.5	5.5

MODEL	d1	d3	D7	L	L28	L2
2100-1/2"	12.70	25	25.40	15	6.50	7.90
2100-5/8"	15.88	26	31.75	15	8.70	10.30
2100-3/4"	19.05	32	34.93	20	8.70	10.30
2100- 1"	25.40	39	41.28	20	9.50	11.10
2100-1 1/8"	28.58	42	44. .45	26	9.50	11.10
2100-1 3/8"	34.93	49	50.80	26	9.50	11.10
2100-1 1/2"	37.10	54	53.98	30	9.50	11.10
2100-1 3/4"	44.45	61	63.50	30	11.10	12.70
2100-2"	50.80	66	69.85	30	11.10	12.70
2100-2 1/8"	53.98	69	76.20	30	12.70	14.30
2100-2 3/8"	60.33	80	82.55	33	12.70	14.30
2100-2 1/2"	63.50	83	85.73	33	12.70	14.30
2100-2 5/8"	66.68	88	85.73	33	14.30	15.90
2100-2 3/4"	69.85	89	88.90	33	14.30	15.90
2100-3"	76.20	99	98.43	40	14.30	15.90
2100-3 1/8"	79.38	103	101.60	40	18.00	19.80
2100-3 1/4"	82.55	104	104.78	40	18.00	19.80
2100-3 3/8"	85.73	108	107.95	40	18.00	19.80
2100-3 1/2"	88.90	112	111.13	40	18.00	19.80
2100-3 5/8"	92.08	114	114.30	40	18.00	19.80
2100-3 3/4"	95.25	118	117.48	40	18.00	19.80
2100-4"	101.6	124	123.83	40	18.00	19.80

MODEL	d1	d3	D7	L4	L2	L1	L12	L13
2100-12	12	22	23	6	5	15	26.5	34
2100-14	14	24	25	6	5	15	29	34
2100-16	16	26	27	6	5	15	29	34
2100-18	18	32	33	6	5	20	31.5	39
2100-20	20	34	35	6	5	20	31.5	39
2100-25	25	39	40	6	5	20	34	44
2100-28	28	42	43	6	5	26	36.5	44
2100-30	30	44	45	7	5	26	35.5	43
2100-35	35	49	50	8	6	26	34.5	47
2100-40	40	56	58	8	6	30	37	47
2100-45	45	61	63	8	6	30	37	52
2100-50	50	66	70	10	8	30	37.5	50
2100-55	55	71	75	10	8	30	37.5	60
2100-60	60	80	80	12	10	33	40.5	58
2100-65	65	85	85	12	10	33	40.5	68
2100-70	70	90	92	12	10	33	48	68
2100-75	75	99	97	12	10	40	48	68
2100-80	80	104	105	14	12	40	47.5	77.5
2100-85	85	109	110	14	12	40	47.5	77.5
2100-90	90	114	115	14	12	40	52.5	77.5
2100-95	95	119	120	14	12	40	52.5	77.5
2100-100	100	124	125	14	12	40	52.5	77.5

Product description

We are pleased to offer the Mechanical Seal John Crane Type 2100K Pump Shaft Seal, a reliable and high-performance sealing solution for various pumps and industrial applications. As a leading manufacturer in China, we aim to provide wholesalers, dealers, and distributors with top-quality products that meet international standards.

Product Name: Mechanical Seal John Crane Type 2100K Pump Shaft Seal

Product Description:

The Mechanical Seal John Crane Type 2100K is a single end face, single bullet mechanical seal designed for pumps used in diverse industries. It features an unbalanced seal with a rubber bellows, ensuring effective sealing and performance. This seal is compatible with water, oil, and sewage with a pH value ranging from 6.5 to 8. It is suitable for applications that require reliable sealing under different operating conditions.

Applications:

The Mechanical Seal John Crane Type 2100K Pump Shaft Seal is suitable for various centrifugal pumps, pipeline pumps, industrial pumps, vortex pumps, and other similar equipment. It is designed to meet the demanding requirements of fluid handling systems in different industries.

We prioritize product quality, performance, and customer satisfaction. Our Mechanical Seal John Crane Type 2100K is manufactured using premium materials and undergoes rigorous quality control processes. We are committed to meeting international standards and delivering products that exceed customer expectations.

If you are interested in partnering with us to distribute the Mechanical Seal John Crane Type 2100K Pump Shaft Seal, please contact us. We look forward to discussing your specific requirements and establishing a successful business relationship.
